HIOKI CLAMP ON PROBE 3275, Wideband Current Probe for Oscilloscopes
HIOKI CLAMP ON PROBE 3275, Wideband Current Probe for Oscilloscopes
HIOKI CLAMP ON PROBE 3275, Wideband Current Probe for Oscilloscopes

HIOKI CLAMP ON PROBE 3275, Wideband Current Probe for Oscilloscopes

0 reviews 0 sold. Only 999 remain
USD $4,334.78 USD $4,782.61 -9%
Negotiable (specific conditions to required)
Brands
Product Code: HIOKI_3275
Stock In Stock
Viewed 110 times
Ship from South Korea
House Brand unavailable (OEM, ODM, OBM)
Dropshipping available
Seller information
  • HIOKI_SY교역
  • South Korea
  • Premium Partner
  • Seller Rating:    0 Reviews
  • Contact Seller
  • Visit Seller's Store

    • Product Description

    The 3275 supports wide DC to 2 MHz bandwidth signals and 500A of continuous high input. The probe is designed with an electrostatic shield to reduce the effects of electric fields, making it ideal for measuring in environments in which the probe will be subjected to the effects of nearby magnetic fields, such as locations with high-voltage switching control equipment such as an inverter or motor.
    - Waveform observation across a wide band from DC to MHz
    - Connects directly to oscilloscope or Memory HiCorder BNC input terminal



    - Frequency bandwidth: DC to 2 MHz (-3 dB)
    - Rise time: 175 ns or shorter
    - Noise level: 2.5 mA rms max. (bandwidth limited to 20 MHz)
    - Continuous allowable input : 500 A rms (requires derating at frequency)
    - Max. allowable peak input: 700 A peak (non continuous) / 500 A peak (pulse width: 30 μs or shorter)
    - Amplitude accuracy (30 min. after power-on, after degaussing and zero-adjustment): ±1.0 % rdg. ±1 mV f.s. (DC, 45 to 66 Hz, 0 to 500 A rms) / ±2.0 % rdg. (DC, 45 to 66 Hz, 500 A to 700 A peak)
    - Output rate:  0.01 V/A (The output of this probe is internally terminated)
    - Measurable conductors: Insulated conductor
    - Core diameter:  φ 20 mm (0.79 in)
    - Power supply: ±12 V ±0.5 V, 5.6 VA max.
    - Dimensions and mass: 176 mm (6.93 in)W × 69 mm (2.72 in)H × 27 mm (1.06 in)D, 520 g (18.3 oz)  / Sensor cable BNC terminal: 2 m (6.56 ft), Power cable: 1 m (3.28 ft)
    - Included accessories: Instruction manual ×1, Carrying case × 1
