HIOKI CLAMP ON PROBE 3274, Wideband Current Probe for Oscilloscopes
HIOKI CLAMP ON PROBE 3274, Wideband Current Probe for Oscilloscopes
HIOKI CLAMP ON PROBE 3274, Wideband Current Probe for Oscilloscopes

HIOKI CLAMP ON PROBE 3274, Wideband Current Probe for Oscilloscopes

0 reviews 0 sold. Only 999 remain
USD $3,548.70 USD $3,913.04 -9%
Negotiable (specific conditions to required)
Brands
Product Code: HIOKI_3274
Stock In Stock
Viewed 93 times
Ship from South Korea
House Brand unavailable (OEM, ODM, OBM)
Dropshipping available
Seller information
  • HIOKI_SY교역
  • South Korea
  • Premium Partner
  • Seller Rating:    0 Reviews
  • Contact Seller
  • Visit Seller's Store

    • Product Description

    The 3274 supports wide DC to 10 MHz bandwidth signals and 150 A of continuous high input, letting you capture transient current signals from switching power supplies, inverters, and motor controllers.
    - Waveform observation across a wide band from DC to MHz
    - Connects directly to oscilloscope or Memory HiCorder BNC input terminal


    - Frequency bandwidth: DC to 10 MHz (-3 dB)
    - Rise time: 35 ns or shorter
    - Noise level: 2.5 mA rms max. (bandwidth limited to 20 MHz)
    - Continuous allowable input : 150 A rms (requires derating at frequency)
    - Max. allowable peak input: 300 A peak (non continuous) / 500 A peak (pulse width: 30 μs or shorter)
    - Amplitude accuracy (30 min. after power-on, after degaussing and zero-adjustment): ±1.0 % rdg. ±1 mV f.s. (DC, 45 to 66 Hz, 0 to 150 A rms) / ±2.0 % rdg. (DC, 45 to 66 Hz, 150 A to 300 A peak)
    - Output rate:  0.1 V/A (The output of this probe is internally terminated)
    - Measurable conductors: Insulated conductor
    - Core diameter:  φ 20 mm (0.79 in)
    - Power supply: ±12 V ±0.5 V, 5.6 VA max.
    - Dimensions and mass: Sensor: Approx. 176 mm (6.93 in)W × 69 mm (2.72 in)H × 27 mm (1.06 in)D, 500 g (17.6 oz)  / Sensor cable BNC terminal: 2 m (6.56 ft), Power cable: 1 m (3.28 ft)
    - Included accessories: Instruction manual ×1, Carrying case × 1
